Shell & Tube

Heat Exchangers

• Pipe and shell sizes up to 120 in. diameter

• Maximum weight of 400,000 lbs

• Maximum shell thickness of 8 in.

• Complete thermal and mechanical design

• Fabricated to ASME Code and TEMA standards

• Materials fabricated:

  • All Nickels

  • 300 and 400 Series Stainless Steel

  • 2205 and 2507 Duplex Stainless Steel

  • Low Alloys

  • Low Temp

  • Carbon Steel

  • Weld Overlays

  • Mill Clads

  • All Chromes

Vessels & Towers

​

• Maximum size up to 192 in. outside diameter

• Maximum weight of 450,000 lbs

• Maximum length of up to 300 ft

• Maximum wall thickness of 8 in.

• Mechanically designed and fabricated to ASME Code

• Materials fabricated:

  • All Nickels

  • 300 and 400 Series Stainless Steel

  • 2205 and 2507 Duplex Stainless Steel

  • Low Alloys

  • Low Temp

  • Carbon Steel

  • Weld Overlays

  • Mill Clads

  • All Chromes

Engineering

​

• Dedicated team of design engineers

• Thermal and mechanical warranties provided on specified projects

• Projects designed and detailed in accordance with ASME, TEMA, and API standards and specifications

​

​

Air Cooled

Heat Exchangers

• Engineered to order

• Maximum weight of 160,000 lbs

• Fabricated to ASME Code and API 661

• We offer the following finned tube types:

  • Embedded Fins

  • Extruded Fins

  • Single and Double L-Footed

  • Slit Fin

• Materials fabricated: Carbon Steel

  • All Nickels, specialists in Inconel and Incoloy

  • 300 and 400 Series Stainless Steel

  • 2205 and 2507 Duplex Stainless Steel

  • Low Alloys and Low Temp

  • Weld overlay of nozzle piping and header box

  • Chrome and Chrome Moly

  • Mill Clads

  • All Chromes

Structural Steel

​

• Voortman 8-axis robotic thermal cutting with up to 50" in width

• Caged and Parapet Ladders

• Mezzanines, Catwalks and Circular Platforms

• Stairs and Circular Tank Walkways

• Pipe and Angle Handrails

• Skids

• Tapered Power Poles and Switch-Yard Structures

• Commercial Buildings

• Trolleys

• Tank Accessories

• Pipe Rack modules

• Columns and Trusses

Bundles

​

• Bundle replacement for air cooled and shell & tube heat exchangers

• 24-7 response for emergency retubing

• In-kind replacements (same/upgraded material) verified by our Thermal and Mechanical engineering teams

• Replacement bundles with upgraded metallurgy as verified by our Thermal and Mechanical engineering teams

• Materials fabricated:

  • All Nickels

  • Titanium

  • 300 and 400 Series Stainless Steel

  • 2205 and 2507 Duplex Stainless Steel

  • Low Alloys and Low Temp

  • Carbon Steel

Specialty & Custom Fabrication

We specialize in unique item fabrication as well as obtaining difficult to procure materials that others cannot source. As with all of our core products, response time and delivery are always prioritized.

​

• Materials fabricated:

  • Carbon Steel (Low Temp, Low Residual Elements)

  • Low Alloy Vanadium Modified

  • 300 and 400 series Stainless Steels

  • Hastelloy

  • Monel

  • Inconel

  • Incoloy

  • Nickel

  • Titanium

  • Aluminum

  • Copper

  • Zirconium
